- Operating voltage: 36V DC
- No-load current: ≤0.5A
- Rated power: 350W
- Hall angle: 120 degrees
- Magnet pole pairs: 15 pairs
- Coil winding: 0.51mm x 5 strands x 12 turns
- Rated speed: 500±30 rpm
- Calculated torque: 15 Nm
- Maximum load: 120 kg
- Hub net weight: 4 kg
- Operating environment temperature: -20°C to +65°C
- Outer diameter/thickness: 255 x 54 mm
