Single-axis DC high-power brushed hub motor
$80.50
1Piece Minimum order
PRODUCT PARAMETERS
- **Operating Voltage**: 24V DC
- **No-Load Current**: ≤0.5A
- **Rated Power**: 250W
- **Hall Angle**: 120 degrees
- **Magnet pole pairs**: 15 pairs
- **Coil winding**: 0.51mm x 5 strands x 12 turns
- **Rated speed**: 300±30 rpm
- **Calculated torque**: 7 Nm
- **Maximum load**: 100 kg
- **Hub Net Weight**: 3.5 kg
- **Operating Temperature Range**: -20°C to +65°C
- **Outer Diameter/Thickness**: 169 × 41.5 mm
- **No-Load Current**: ≤0.5A
- **Rated Power**: 250W
- **Hall Angle**: 120 degrees
- **Magnet pole pairs**: 15 pairs
- **Coil winding**: 0.51mm x 5 strands x 12 turns
- **Rated speed**: 300±30 rpm
- **Calculated torque**: 7 Nm
- **Maximum load**: 100 kg
- **Hub Net Weight**: 3.5 kg
- **Operating Temperature Range**: -20°C to +65°C
- **Outer Diameter/Thickness**: 169 × 41.5 mm
