Motor Diameter    200mm
Rated Voltage    36V
Rated Power: 250W
Rated Speed: 500±30 rpm
Rated Current: 5±0.5 A
Theoretical Torque: 10.9 N/m
Phase Angle: 120°
Pole Number: 15 Pairs of Poles: 30
Magnet Dimensions: 38M; 30mm × 11.2mm × 3mm
Enameled wire specification    Enameled round copper wire    QZ-C180
Coil winding    0.51#512
Stator core dimensions    105#    3.5
Number of slots    27
Lead wire specification    3×1.5²-5×0.1²
Exposed lead wire length    300mm
No-load current    ≤0.3A
Withstand voltage    0.5 kV ≤10 mA
Insulation resistance    ≥500 MΩ
Shaft material    45 steel
Shaft type    Single-sided shaft
D-shaped clamp type
Waterproof rating    IP54
Maximum load    80 kg
Environmental requirements    -20°C to 65°C
