Model | Rated Voltage | No-load Speed | No-load Current | Rated Torque | Rated Speed | Rated Current | Rated Output |
V | r.p.m. | A | mN.m | r.p.m. | A | W | |
IBL-90SW01 | 36 | 7000 | 4.72 | 2000 | 5300.0 | 37.0 | 1120.0 |
IBL-90SW02 | 36 | 3700 | 4.0 | 2500 | 2800.0 | 28.0 | 750 |
IBL-90SW03 | 36 | 6000 | 5.0 | 2700 | 4500.0 | 37.0 | 1286 |
IBL-90SW04 | 12 | 3552 | 3.2 | 400 | 3028.0 | 16.7 | 140 |
IBL-90SW05 | 24 | 3100 | 1.6 | 58 | 2750.0 | 15.0 | 302 |
