- Rated Power (W): 3000
- Voltage: 48V
- Rated Current: 75A
- Maximum Phase Current: 240A
- Maximum Current Duration: 10s
- Rated Speed: 3600rpm
- Rated Torque: 8N.m
- Peak Torque: 25N.m
- Interphase Resistance: 13.8mΩ
- Inductance: 118μH
- Number of pole pairs: 4
- Insulation class: H
- Protection rating: IP65
- Magnetic field type: Axial
- Cooling method: Air-cooled/Water-cooled
- Diameter: 182mm
- Height: 107mm (Air-cooled), 110mm (Water-cooled)
- Shaft diameter: 20mm
- Net weight: 7.6kg
