Voltage
12 V
Rated Current
40 A
Maximum Operating Current
40A
Maximum Operating Voltage
27VDC
Nominal Operating Power
1.6W, 1.8W
Ambient Temperature
-40°C to +85°C
Rated Voltage
DC12V/24V
Rated Load (Resistive Load)
1A: 40A  13.5VDC    20A  27VDC
1C: NO/NC    40A/30A  13.5VDC      20A/15A  27VDC
Insulation Resistance
100MΩ
Dielectric Strength (Coil and Contact)
500VAC/M
Ambient Temperature
-40°C to +85°C
