300A Automotive Starter Relay 12V 200A 24VDC
1Piece Minimum order
PRODUCT PARAMETERS
Type |
Relay |
|---|---|
Category |
Automotive |
Voltage |
12V |
Voltage
12V
Rated Current
200A
Maximum Operating Current
300A
Coil Data
30Ω±10% 89Ω±10%
Coil Rated Voltage
12VDC 24V DC
Rated Coil Power
4.8W 6.5W
Pull-in Voltage
≤ 8VDC ≤ 17VDC
Release Voltage
≥ 1.2VDC ≥ 2.4VDC
Operating Time
<30 milliseconds
Release Time
<15 milliseconds
