Maximum continuous current: 40A
Operating temperature up to 85°C
Coil Voltage Type: DC
Coil Operating Voltage: 24
Contact Configuration: Two Sets of Normally Open
Number of Contacts: Single Contact
Terminal Configuration: PCB Mount and Bolt Mount
Mounting Method: PCB and Bolt Mounting
Package Type: Solder Mask Type
Coil Power: Standard Type
Coil Characteristic: Monostable
Load Voltage: 250
Rated Coil Power    Approx. 4.8W
Dielectric Withstand Voltage    4000VAC 1min
Actuation Time (Unit: ms)    ≤30
Release Time (Unit: ms)    ≤5
Maximum Rated Switching Current (AC)    40
Temperature Range    -40°C to 85°C
