Maximum continuous current 40A
Operating temperature up to 85°C
Coil Voltage Type    DC
Coil Operating Voltage    12
Contact Configuration    Two sets of normally open contacts
Number of Contacts    Single contact
Terminal Configuration    PCB and bolt-type
Mounting Configuration    PCB and bolt mounting
Package Type    Solder mask type
Coil Power    Low power consumption type
Coil Characteristics    Monostable
Load Voltage    250
Rated Coil Power    Approx. 3.8W
Dielectric Withstand Voltage    4000VAC 1min
Actuation Time (Unit: ms)    ≤30
Release Time (Unit: ms)    ≤5
Maximum Rated Switching Current (AC)    40
Maximum Switching Voltage (AC)    277
Temperature Range    -40 ℃ - 85 ℃
