1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12
3. Contact Form: One Set Normally Open
4. Number of Contacts: Single Contact
5. Terminal Form: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Solder Mask Type
8. Coil Power: Standard Type
9. Coil Feature: Monostable
10. Contact Material: AgSnO₂
11. Packaging Type: Tube Packaging
12. Load Voltage: 12V
13. Rated Coil Power: Approx. 0.48W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Actuation Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤10
17. Insulation Resistance (Unit: MΩ): 100
18. Maximum Rated Switching Current (DC): 30
19. Maximum Switching Voltage (DC): 16
20. Temperature Range: -40°C to 125°C
21. Mechanical Durability (Unit: Cycles): 10,000,000
22. Electrical endurance (units): 100,000
23. Application fields: Window defogging #Headlight control #Seat heating control #Power window control, etc.
24. Weight (units: g): Approx. 5.0
25. Dimensions (units: mm³): 14×9.2×14
