25A motor load
Ultra-compact
Changeover contact form
 Single or dual relays available
H-class (180°C) coil insulation rating
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Form: One set changeover
4. Number of Contacts: Single contact
5. Terminal Form: PCB-mount
6. Mounting Type: PCB mounting
7. Package Type: Solder Mask Type
8. Coil Power: Low Operating Voltage Type
9. Coil Characteristic: Monostable
10. Contact Material: AgSnO₂
11. Load Voltage: 12V
12. Rated Coil Power: Approx. 0.8W
13. Dielectric Withstand Voltage: 500VAC 1min
14. Actuation Time (Unit: ms): ≤10
15. Release Time (Unit: ms): ≤10
16. Insulation Resistance (Unit: MΩ): 100
17. Maximum rated switching current (DC): 25
18. Maximum switching voltage (DC): 16
19. Temperature range: -40°C to 125°C
20. Mechanical endurance (cycles): 10,000,000
21. Electrical endurance (cycles): 100,000
22. Product Application Fields: Automatic doors/windows, central door locks, sunroof control, seat adjustment, indicator light control, wiper control, etc. (The period after “central door locks” in the original text has been corrected to a comma to maintain consistent enumeration logic)
23. Weight (Unit: g): Approx. 4
24. Volume (Unit: mm³): 14×7.2×14.2
