20A contact switching capacity
Available in six contact configurations
Open-frame and molded-case options
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 6V
3. Contact Configuration: Double-Throw
4. Number of Contacts: Dual
5. Terminal Configuration: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Molded
8. Coil Power: Standard
9. Coil Characteristic: Monostable
10. Contact Material: AgSnO₂
11. Packaging: Tube
12. Load Voltage: 6V
13. Rated Coil Power: Approx. 1.1W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Actuation Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤10
17. Maximum Rated Switching Current (DC): 30
18. Maximum Switching Voltage (DC): 90
19. Temperature Range: -40°C to 85°C
20. Mechanical Endurance (Unit: Cycles): 10,000,000
21. Electrical endurance (units): 200,000
22. Application fields: Indicator/illumination/flashing light control, instrumentation, automatic doors/windows, cold start, central door locks, sun visor control
23. Weight (units: g): Approx. 12
24. Dimensions (units: mm³): 17.5 × 15 × 19.5
