Maximum continuous current: 50A
Maximum closing current: 200A
Operating temperature up to 125°C
1. Coil voltage type: DC
2. Coil operating voltage: 12V
3. Contact configuration: One set of normally open contacts
4. Number of contacts: Single contact
5. Terminal type: PCB-mount
6. Mounting type: PCB mounting
7. Package Type: Solder Mask Type (Reflow Soldering)
8. Coil Power Rating: Standard
9. Coil Feature: Dual-Coil Magnetic Retention
10. Contact Material: AgSnO₂
11. Packaging: Tape and Reel
12. Load Voltage: 13.5V
13. Rated Coil Power: Approx. 7.2W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Operating Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤5
17. Insulation Resistance (Unit: MΩ): 100
18. Maximum Rated Switching Current (DC): 40
19. Maximum Switching Voltage (DC): 16
20. Temperature Range: -40°C to 125°C
21. Mechanical Endurance (Unit: Cycles): 1,000,000
22. Electrical endurance (units): 100,000 (For more details, please refer to the datasheet)
23. Product application areas: Power management, engine control, ignition, main switch power supply relays, preheating systems, static current management
24. Weight (units: g): Approx. 9
25. Volume (units: mm³): 18.3 × 16 × 15.9
