ATS-100:

Number of bars: ≤36

Inter-chip resistance: ≤±0.5% full-scale

Welding resistance: ±10μΩ

180 resistance: ≤±0.5% full-scale

Surge: ±2.5%

Isolation resistance: 0.1-500MΩ ≤±2.5% full-scale

Hipot: 0-20mA ≤±2.5% full-scale

Size of Equipment: 930mm×1240mm×560mm

Equipment environment:

Power: AC220V ±10% @50Hz

Air pressure: 0.4-0.6Mpa

Temperature: 0-45℃

The system supports up to 3 power-frequency withstand voltage test configurations, accommodating diverse product testing needs.

By implementing a function-module-based architecture, the equipment achieves enhanced operational stability while simplifying maintenance and service procedures.
