Starter Relay Compatible with Honda TRX450ES FOURTRAX FOURMAN 1998-2001
1Piece Minimum order
PRODUCT PARAMETERS
Type |
Relay |
|---|---|
Category |
Automotive |
Brand |
Xiaoxibian |
For Honda Models:
TRX450ES FOURTRAX FOURMAN 1998-2001
Part Type Starter Solenoid Relay OEM Equivalent Part Number 35850-HM7-000, 35850-HM7-A00 Material Construction High-temperature copper core coil, flame-retardant ABS housing, corrosion-resistant zinc alloy terminals Nominal Voltage Rating 12V DC Maximum Continuous Current Rating 150A Peak Inrush Current Capacity 300A Mounting Hole Diameter 6mm / 0.24 inch Terminal Configuration 4-pin Waterproof Ingress Protection Rating IP65 Operating Temperature Range -40°F to 221°F / -40°C to 105°C Installation Type Direct drop-in replacement, no modification needed Package Contents 1 x Starter Relay, 2 x Mounting Screws Service Life Up to 100,000 operation cycles under rated load
