Compatible with Yamaha Models:
Raptor SE YFM700R 2007-2012

Length: 47 mm - 1.9 in
Width: 41 mm - 1.6 in
Height: 51 mm - 2.0 in



Operating Voltage 12V DC Terminal Material High conductivity copper alloy with tin plating Rated Continuous Current Capacity 150A Peak Current Capacity 300A (10 seconds maximum) Mounting Hole Diameter 6 mm - 0.24 in Mounting Hole Center Spacing 32 mm - 1.26 in Ingress Protection Rating IP65 dustproof and water jet resistant Coil Resistance 15 ohms ± 10% tolerance Operating Temperature Range -40°C to 125°C (-40°F to 257°F) Replacement OEM Part Number 1S3-81940-00-00 Connector Type 4-pin male spade connector Core Material High permeability ferrosilicon alloy Service Life Rating Minimum 100,000 operation cycles
