Voltage 12V 24V
Rated Current 30A
Contact Type Changeover
Power Consumption 1.6W
Unit Weight 40g

Coil Resistance 90Ω (12V) / 360Ω (24V) Contact Material Silver Tin Oxide (AgSnO₂) Operating Temperature Range -40℃ to +125℃ Insulation Resistance ≥100MΩ (500V DC) Dielectric Strength 1500V AC (1 minute, coil to contact) Mechanical Lifespan ≥10,000,000 operations (no load) Electrical Lifespan ≥100,000 operations (rated load) Terminal Configuration 5-Pin SPDT Seal Rating IP65 (main body) Mounting Type Plug-in Blade Terminal Pickup Voltage ≤9V (12V model) / ≤18V (24V model) Dropout Voltage ≥1.5V (12V model) / ≥3V (24V model)
