Supply voltage：AC 220V+ 10% 50HZ
Source pressure：0.45-0.7Mpa
Rated power：2.5KW
Rated speed：2000-4500rpm
Counting accuracy：+0.01/circle
Line type precision：0.01mm
Angular accuracy：0.1°
Optimum winding diameter：Φ0.04-Φ0.60mm
Overall dimension：1400x700x1800mm
Machine weight：300KG
Scope of application:
Φ15 to Φ42mm heat dissipation fan core high quality winding.
Efficiency reference:
Take Φ18mm iron core, 0.25mm wire diameter, 98T per pole as an examole, about 280PCS/h.
