Motor Design: PMSM
Matching Tires: 14 - 19 inch
Magnet Height: 90 hours
Rated Power: 7500W
Peak Power: 13500W
Rated Voltage: 48v - 96v
Speed: 4000 rpm @ 72v, 6500 rpm after flux reduction
Max Torque: 72N.m
Cooling Method: Air Cooled
Max Efficiency: 93%
Thermal Probe: KTY83 - 122
Operating temperature: 70 - 120 °C, peak 150 °C
Hall sensors: 1 set
Phase cable: 20 mm² cross section of phase wires (excluding insulation)
Waterproof rating: IP67
Color: Black
N.W./G.W.: 13 kg/14 kg
Packing size: 34 cm * 33 cm Arrangement
