Input Unit: six-channel

Basic Accuracy: 0.01 class ±(0.01% of reading + 0.05% of range)

Measurement Bandwidth: DC & 0.5Hz-300KHz

Input Range:

Voltage range: 15V 30V 50V 75V 150V 300V 500V 1000V

Current range:

50A input unit:

200mA 500mA 1A 2A 5A 10A 20A 50A

5A Input Unit:

20mA 50mA 100mA 200mA 500mA 1A 2A 5A

Measured parameters

Voltage U, current I, frequency f, active power P, reactive power Q, apparent power S, power factor PF,

Peak voltage U±PK, Peak current I±PK, Peak factor CF, Power accumulation E, Harmonic distortion, Harmonic components, Efficiency, etc.

Allowable overload: 120% of voltage and current range

Line filtering:

Analog filter: cutoff frequency of 500Hz

Digital filter: Cutoff frequency is 1KHz to 100kHz.

(Continuously adjustable in steps of 100Hz up to 10KHz, and continuously adjustable in steps of 1KHz above 10KHz.)

Frequency filter: Cutoff frequency is 500Hz.

Efficiency Measurement: Input and output efficiency can be tested

Speed and torque: optional: speed and torque interface

Display: 8-inch color LCD touch screen 800*600 points (H*V)

Communication interface: standard: USB, RS232, RS485 and Ethernet port

Instrument weight: about 12Kg

Overall Power Consumption: ＜25VA

Working Power Supply: AC 85V～265V, 50/60Hz

Overall dimensions: width × height × depth 442*198*435
