MOTOR TYPE: BLDC Outrunner Hub Motor with Hall Sensor
MOTOR DESIGN: Dual Axis with 12 inch moped rims (integrated)
Rim size: 12x3.5 inch (narrow tire by default), Matching tires: 130/90-12, etc.
PS: For tires with a width of 12*5.0 inches, it will cost you an additional $15.0/PCS.
MAGNET HEAVY: 35mm, 16 Pole Pair
Stator: Aluminum Core
Rated Power: 2000W
Speed: 30KPH-90KPH, it is customized, usually we will design it for 72V75KPH.
Operating Voltage Range: 48V-96V, default is 72V.
Maximum Torque Approx. 195.0N.m
KV: 8.5/10.0/11.87/ 16.25/21.46 (optional)
Thermal probe: KTY83-122 (default, optional)
Maximum efficiency approx. 88%
Brake type: disc brake (default), PCD3*80mm-M8, CB 58mm
Dropout: 200mm (customizable 230mm)
Dual Hall with waterproof connector (1 spare in case of damage)
16mm² phase cable
Waterproof rating: IP54
Color: Black
