Motor Type: BLDC Outrunner Hub Motor with Hall Sensor
Motor Design: Dual Axis with 12-inch Moped Rims (Integrated)
Rim Size: 12x3.5 inches
Magnet Height: 60mm, 16 Pole Pair
Stator: Aluminum Core
Rated Power: 8,000W
Speed: 30KPH-130KPH, it is customized, usually we will design it for 72V100KPH.
Operating voltage range: 48V-96V, default is 72V.
Maximum torque approx. 330N.m
KV: depends on customer's maximum speed requirement (optional)
Thermal probe: KTY83-122 (default, optional)
Maximum efficiency approx. 88%
Brake type: Disc brake (default), PCD3*80mm-M8, CB 58mm
Disengagement: 230mm
Dual Hall with waterproof connector (1 spare in case of damage)
25mm² phase cable
Waterproof rating: IP54
Colors: black (default), yellow or white/luminous
