Voltage(V): 72 / 96 / 120
Voltage: 48volt / 72volt / 96volt
Rated Power(watt): 15000
Power Rate: 20KW
Peak Power: 50kW
Rated Current(A): 245 / 185 / 150
Continuous Current(A): 325/245A
Max Phase Current(A): 800 / 600 / 500
Max Phase Current (A): 10
Rated Speed(rpm): 3500
Speed(RPM): 3200-5000 revolutions / min
Speed: 3200-6000 revolutions / min
Rated Torque(N.m): 40
Peak Torque(N. m): 100 Torque: 55 m): 100
Torque: 55N・m
Rated Torque: 80N・m
Peak Torque: 160 knots
Efficiency: >90%
Number of Pole-Pairs: 4
Protection Lever: IP65
Cooling: water-cooled
Weight: 39 kg
