Description
Model | ZD101A1 | ||
Rated Power/W | 200 | 250 | 350 |
Rated Voltag/V | 24 | 24/36 | 24/36 |
Unload Current/A | ≤1.2 | ≤1.4 | ≤1.4 |
Unload Speed/RPM | 3350 | 3350 | 3350 |
RATED Torque/N.M | 0.69 | 0.86 | 1.2 |
Rated Speed/RPM | 2750 | 2750 | 2750 |
Rated Current/A | ≤10.7 | ≤13.3/8.9 | ≤18.7/12.5 |
Efficiency/% | ≥78 | ≥78 | ≥78 |
Work System/Min | S2:60 | ||
Insolation Grade | E | ||
Use | 24v Brush Motor | ||
Wattage: 201 - 350w
Product name: MY1016
Rated Output Power: 200/250/350 W
Product rated Voltage: 24 V/36V
This 24v Brush Motor is always used for Scooter,Small Electric motorcycle
