1 years
China
Certification
Manufactured in ISO9001‑certified production facility. CE documents available upon buyer’s request.
13. Real Product Photos
Pinion bevel gear overview shot, bevel tooth close‑up view, inner spline detail view, outboard gear‑case installation reference picture
14. Independent Product Description
This rugged marine 13‑tooth pinion bevel gear serves as a reliable aftermarket replacement matching OEM part numbers 6E7‑45551‑00 and 6E7‑45551‑01. It is manufactured for Yamaha 9.9‑horsepower and 15‑horsepower outboard motors for lower‑unit transmission repair.
Built from wear‑resistant quenched alloy steel, this component goes through accurate CNC machining alongside thorough heat‑treatment steps. Its solid construction maintains steady structural rigidity under continuous torque loads and salt‑spray marine surroundings. Hardened bevel gear teeth hold up against chipping and scuffing during repeated forward‑reverse gear shifts.
Every shaft‑hole measurement and spline dimension closely meets OEM tolerance benchmarks. Fitters can complete quick, exact installation, and no trimming or secondary rework is necessary.
This practical service‑grade aftermarket part resolves common gear‑case troubles, such as choppy power transmission, grinding gear noise, gear jumping and heavily worn‑down tooth surfaces. Swapping out the aged pinion bevel gear restores stable power transfer inside your outboard gear case. Be sure to refer to the official factory service manual for proper mounting and gear‑oil top‑up. Once assembled correctly, your Yamaha outboard will deliver reliable power‑output performance on open water.
Product Name Pinion Gear
OE Number 6E7-45551-00(8 Teeth)
Application Yamaha Outboard Motor 9.9HP,15HP,F9.9,F15,F20
