Verify the part fits before purchasing
Top End Gasket Kit for Yamaha
Applications:
Yamaha Mountain Max 700 1997 - 2003, SX700R 2001, SX700SD 2000, V Max 700 1999 - 2001, V Max 700 Deluxe 1999 - 2001, V Max 700 SX 1997 - 1999, V Max 700 XT 1998, V Max 700 XTC 1998, V Max 700ER 2002, Venture 700 1998 - 2003
Gasket Construction Material Nitrile Butadiene Rubber (NBR) + reinforced graphite composite blend Operating Temperature Resistance Range -40°F to 500°F (-40°C to 260°C) Compatible Engine Type 700cc 2-stroke triple-cylinder snowmobile engine Kit Component Count 24 precision-cut sealing components Included Accessory 1 x 0.5oz high-temperature RTV silicone sealant tube Cylinder Head Gasket Thickness 0.040 inch (1.016mm) OEM-matching thickness Combustion Pressure Resistance Rating Up to 220 PSI operational pressure capacity Required Mating Surface Finish 30 Ra (microinch) maximum surface roughness for optimal seal OEM Part Cross Reference Compatible with Yamaha OEM part numbers 4XV-11181-00-00, 8CR-11351-00-00, 8CR-11193-00-00 Corrosion Resistance Property Resistant to ethanol-blended fuel, engine oil, and coolant degradation
