Starter Drive for ISUZU 11 teeth dimension 39.7

1. Basic Information     Developed for ISUZU equipment, this starter drive comes with 11 pinion teeth and measures 39.7mm. Crafted from high-hardness alloy steel, it handles continuous heavy cranking pressure. Precise dimension allows trouble-free fitting, while the overrunning clutch avoids reverse impact failure. This interchangeable component recovers stable starting power for matching ISUZU starter assemblies.

• Item: Starter Drive Gear

• Function: Meshes with the engine flywheel to transfer starter torque for smooth engine startup.

• Model: XH-657

2. Compatibility

• Brand: ISUZU (for its starter systems).

3. Specifications

• Teeth (T): 11

• G Dimension: 39.7

• Length (L): 94

• Splines (SPL): 10

• Inner Diameter (ID): 12

• Diameter (D): 53.2

• Rotation Direction: Clockwise (CW)

4. OEM Reference Code

No specific OEM code is shown in the diagram. Please confirm the matching OEM number based on the specific vehicle model.
