1 years
China
Specifications: 80A 9.5mm
Contact Form SPST (Single Pole Single Throw, Normally Open) Rated Coil Voltage 12V DC (24V DC variant available for bulk custom orders) Coil Power Consumption 1.8W ± 10% Maximum Switching Voltage 72V DC Rated Load Current 80A at 14V DC Contact Material Silver Tin Oxide (AgSnO₂) Standard Foot Pitch Width 9.5mm Operating Temperature Range -40°C to +125°C Insulation Resistance ≥ 100MΩ at 500V DC Dielectric Strength 1500V AC for 1 minute (between coil and contact terminals) Mechanical Lifespan ≥ 10,000,000 cycles (no-load operation) Electrical Lifespan ≥ 100,000 cycles (rated load operation) Terminal Type Unwired bare copper pin terminals Vibration Resistance 10Hz to 2000Hz, 10g acceleration, no functional damage Ingress Protection Rating IP20 (for dry automotive cabin/engine bay installation)
