1 years
China
Maximum switching voltage: 14V
Maximum switching current: 80A
Contact configuration: Normally open/changeover
Coil power: 1.8W
Coil Voltage Options 12V DC, 24V DC Pin Count Options 4-Pin, 5-Pin Mounting Type PCB Through-Hole Solder Contact Material Silver Tin Oxide (AgSnO₂) Insulation Resistance ≥100MΩ @ 500V DC Dielectric Strength 1500V AC for 1 minute (coil to contact) Operating Temperature Range -40°C to +125°C Mechanical Lifespan ≥10,000,000 no-load operations Electrical Lifespan ≥100,000 rated-load operations Pick-Up Voltage ≤75% of rated coil voltage Drop-Out Voltage ≥10% of rated coil voltage Sealing Grade IP67 (dustproof, splash and temporary immersion resistant) Vibration Resistance 10~2000Hz, 1.5mm amplitude, no malfunction Shock Resistance 100G, 11ms duration, no structural damage or malfunction
