1 years
China
Rated Current: 40A
Coil Rated Voltage 12V DC Coil Resistance 90Ω ±10% Contact Configuration SPDT (Single Pole Double Throw) Rated Load Capacity 40A 14V DC (Normally Open), 30A 14V DC (Normally Closed) Operating Temperature Range -40°C to +125°C Insulation Resistance ≥100MΩ at 500V DC Dielectric Strength 1500V AC for 1 minute between coil and contact terminals Mechanical Service Life ≥10,000,000 no-load operations Electrical Service Life ≥100,000 rated-load operations Mounting Type Through-hole PCB soldered plug-in Terminal Material Tin-plated copper alloy Housing Material Flame-retardant PA66, UL94 V-0 rated Pick-up Voltage ≤9V DC at 25°C Drop-out Voltage ≥1.2V DC at 25°C Maximum Operating Voltage 15.6V DC Protection Grade IP40 for exposed terminal side, IP67 for sealed body section
