1 years
China
Maximum switching voltage: 14VDC/28VDC
Maximum switching current: 80A
Rated coil voltage: 12V DC/24V DC
Contact break time: 5ms/7ms/9ms
Coil power: 1.8W
Contact Form SPST (4-pin) / SPDT (5-pin) Coil Resistance 80Ω (12V DC) / 320Ω (24V DC) Contact Material Silver Tin Oxide (AgSnO₂) Mechanical Endurance ≥10,000,000 Cycles (No Load Condition) Electrical Endurance ≥100,000 Cycles (Rated 80A Load Condition) Insulation Resistance ≥100MΩ (Tested at 500V DC) Dielectric Strength 1500V AC (1 Minute, Coil to Contact Gap) Operating Temperature Range -40°C to +125°C Protection Rating IP67 (Dustproof, Waterproof for Short-Term Immersion) Pick-up Voltage ≤9V (12V Coil) / ≤18V (24V Coil) Drop-out Voltage ≥1.2V (12V Coil) / ≥2.4V (24V Coil) Terminal Type Quarter-inch Quick-Connect Blade Terminals
