Maximum continuous current: 40A
Maximum make current: 120A
Ambient temperature up to 125°C
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Configuration: Single-Pole Changeover
4. Number of Contacts: Single Contact
5. Terminal Configuration: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Solder Mask Type
8. Coil Power: 0.64W
9. Coil Feature: Monostable
10. Contact Material: AgSnO₂
11. Packaging Type: Tube
12. Load Voltage: 12
13. Rated Coil Power: Approx. 0.64W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Actuation Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤10
17. Insulation Resistance (Unit: MΩ): 100
18. Maximum Rated Switching Current (DC): 40
19. Maximum Switching Voltage (DC): 16
20. Temperature Range: -40°C to 125°C
21. Mechanical Endurance (Unit: Cycles): 5,000,000
22. Electrical endurance (units): 100,000 (For more details, please refer to the sample)
23. Product application areas: Headlight control, heating control, oil pump control, etc.
24. Weight (units: g): Approx. 6.5
25. Volume (units: mm³): 14.4 × 11 × 16
HFK8-T/12-ZPT Single-Pole Changeover 0.64W Automotive Relay
US$ 8.99 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This HFK8-T/12-ZPT single-pole changeover 0.64W automotive relay is compatible with all 12V automotive electrical systems, fitting most sedans, SUVs, light trucks, and modified off-road vehicles as a direct OEM replacement.
- Built with high-purity copper conductive contacts, a heat-resistant PA66 housing, and internal anti-vibration components, this relay delivers stable, low-loss performance even in high-temperature, high-dust underhood environments.
- This is a brand new, factory-calibrated HFK8-T/12-ZPT relay with no prior use, wear, or defects, fully tested to meet or exceed original equipment performance standards for long service life.
- Perfect for controlling vehicle lighting upgrades, cooling fans, fuel pumps, car audio power circuits, and winch control systems, this single-pole changeover relay supports seamless switching between two independent circuit paths.
- Each relay ships in a sealed anti-static bag with shock-absorbent padding, paired with a quick-start installation guide to prevent transit damage and simplify setup for both professional mechanics and DIY enthusiasts.
