Maximum continuous current: 50A
Maximum make current: 200A
Ambient temperature up to 125°C
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Configuration: One Set Normally Open
4. Number of Contacts: Single Contact
5. Terminal Configuration: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Solder Mask Type
8. Coil Power Rating: Sensitive Type
9. Coil Characteristic: Monostable
10. Contact Material: AgSnO₂
11. Packaging Type: Tube or Tape
12. Load Voltage: 12V
13. Rated Coil Power: Approx. 0.64W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Actuation Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤10
17. Insulation Resistance (Unit: MΩ): 100
18. Maximum rated switching current (DC): 30
19. Maximum switching voltage (DC): 16
20. Temperature range: -40°C to 125°C
21. Mechanical endurance (cycles): 10,000,000
22. Electrical endurance (cycles): 100,000
23. Product Application Areas: Rear window defogging, light control, horn control, seat heating control, wiper control, cooling fan, start-stop control, ERS, etc.
24. Weight (Unit: g): Approx. 10
25. Volume (Unit: mm³): 17.8 × 13 × 16.4
HFK9-T/12-1HLT Single Normally Open 12VDC Automotive Relay
US$ 9.99 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This HFK9-T/12-1HLT single normally open 12VDC relay is compatible with most passenger cars, light trucks, and aftermarket electrical modification projects that match its listed form factor and performance specs.
- Built with heavy-duty copper alloy conductive contacts and a heat-resistant, flame-retardant thermoplastic housing, this relay resists corrosion, vibration, and under-hood temperature extremes for long-term reliable operation.
- This is a brand new, factory-tested HFK9-T/12-1HLT relay that meets all original equipment performance standards, with no defects, wear, or prior use of any kind.
- Perfect for powering auxiliary headlights, cooling fans, audio amplifiers, fog lights, and other high-current automotive accessories, this normally open relay protects your vehicle’s factory wiring from overload damage.
- Each individual HFK9-T/12-1HLT relay is shipped in anti-static, shock-absorbent protective packaging to eliminate risk of electrical or physical damage during transport and storage.
