25A motor load
Ultra-compact
Normally open and changeover types available
Single or dual relays available
30A fuse rating available
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Form: One Changeover Set
4. Number of Contacts: Single Contact
5. Terminal Form: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Solder Mask Type
8. Coil Power: Monostable Low Power Type
9. Coil characteristic: Monostable
10. Contact material: AgSnO₂
11. Load voltage: 12
12. Rated coil power: Approx. 0.48W
13. Dielectric withstand voltage: 500VAC 1min
14. Actuation time (unit: ms): ≤10
15. Release time (unit: ms): ≤10
16. Insulation Resistance (Unit: MΩ): 100
17. Maximum Rated Switching Current (DC): 25
18. Maximum Switching Voltage (DC): 16
19. Temperature Range: -40°C to 125°C
20. Mechanical Durability (Unit: Cycles): 10,000,000
21. Electrical endurance (units): 100,000
22. Application fields: Automatic doors/windows, central door locks, sunroof control, seat adjustment, indicator light control, wiper control, etc.
23. Weight (units: g): Approx. 4
24. Dimensions (units: mm³): 14 × 7.2 × 14.2
A set of 0.48W automotive relays HFKAH-T/12-1ZLT low power consumption
US$ 15.99 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This 0.48W HFKAH-T/12-1ZLT automotive relay set is universally compatible with most 12V passenger cars, light trucks, and modified off-road vehicles, seamlessly matching standard factory wiring harness specifications for easy plug-and-play installation.
- Crafted with high-purity copper contact points and flame-retardant, high-temperature resistant ABS casing, these low-power 0.48W automotive relays deliver stable conductivity and resist short-circuit damage even under harsh under-hood operating conditions.
- All relays in this HFKAH-T/12-1ZLT set are 100% brand new and factory-tested for consistent performance and zero defects before shipment, guaranteeing reliable long-term operation for your vehicle systems.
- Ideal for controlling vehicle lighting systems, cooling fans, fuel pumps, and aftermarket accessory circuits, these low-power 0.48W automotive relays cut unnecessary idle power draw to extend your vehicle's battery life significantly.
- Each set of HFKAH-T/12-1ZLT automotive relays comes securely packaged in a shock-resistant electrostatic bag to prevent transit damage, with a clear product specification label for easy identification and inventory management.
