25A motor load
Ultra-compact
Normally open and changeover types available
Single or dual relays available
30A fuse rating available
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Form: One Set Normally Open
4. Number of Contacts: Single Contact
5. Terminal Form: PCB Mount
6. Mounting Type: PCB Mount
7. Package Type: Solder Mask Type
8. Coil Power: Monostable Low Power Type
9. Coil Characteristic: Monostable
10. Contact Material: AgSnO₂
11. Load Voltage: 12
12. Rated Coil Power: Approx. 0.48W
13. Dielectric Withstand Voltage: 500VAC 1min
14. Actuation Time (Unit: ms): ≤10
15. Release Time (Unit: ms): ≤10
16. Insulation Resistance (Unit: MΩ): 100
17. Maximum Rated Switching Current (DC): 25
18. Maximum Switching Voltage (DC): 16
19. Temperature Range: -40°C to 125°C
20. Mechanical Durability (Unit: Cycles): 10,000,000
21. Electrical endurance (units): 100,000
22. Application fields: Automatic doors/windows, central door locks, sunroof control, seat adjustment, indicator light control, wiper control, etc.
23. Weight (units: g): Approx. 4
24. Dimensions (units: mm³): 14 × 7.2 × 14.2
0.48W Normally Open Automotive Relay HFKAH-T/12-1HLT Low Power
US$ 15.99 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This 0.48W low power normally open automotive relay is designed as a direct drop-in replacement for HFKAH-T/12-1HLT relay models, and fits most 12V passenger cars, light trucks, and custom automotive electrical builds.
- Built with high-conductivity copper contact pins and a flame-retardant, impact-resistant ABS housing, this relay withstands extreme under-hood heat, vibration, and moisture for long-lasting, reliable performance.
- This is a brand new, factory-calibrated automotive relay with zero prior use, full functionality testing completed at the manufacturing facility to eliminate defects and early failure risks.
- Perfect for controlling auxiliary lighting, cooling fans, car audio systems, and aftermarket power accessories, this low-power normally open relay minimizes idle power draw to extend your vehicle's battery service life.
- Each relay ships in an individual anti-static sealed bag to prevent electrostatic damage during transit and storage, so you receive a fully intact, ready-to-install component every time.
