30DC Automotive Relay HFKC/012-HST One Set Normally Open

Ultra-compact automotive relay
Weight: Only 4 grams (single relay)
Single or dual relays available
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Form: One set normally open
4. Number of Contacts: Single contact
5. Terminal Form: PCB-mounted
6. Mounting Type: PCB mounting
7. Package Type: Plastic-encapsulated
8. Coil Power Rating: Standard
9. Coil Characteristic: Monostable
10. Contact Material: AgSnO₂
11. Packaging: Tube & Carton
12. Load Voltage: 13.5V
13. Rated Coil Power: Approx. 0.55W
14. Dielectric Withstand Voltage: 500VAC 1min
15. Actuation Time (Unit: ms): ≤10
16. Release Time (Unit: ms): ≤10
17. Insulation Resistance (Unit: MΩ): 100
18. Maximum Rated Switching Current (DC): 30
19. Maximum Switching Voltage (DC): 16
20. Temperature Range: -40°C to 105°C
21. Mechanical Endurance (Cycles): 10,000,000
22. Electrical Endurance (Cycles): 300,000 (For more details, please refer to the sample)
23. Product Application Areas: Central door locking, Wiper control, Instrument panel control, Automatic doors/windows, Anti-theft systems, Rear window and seat heating control, Lighting/flashing/indicator light control
24. Weight (Unit: g): Approx. 4
25. Volume (Unit: mm³): 12.9 × 12 × 9.9
