Maximum continuous current: 130A (85°C), 150A (23°C)
Supports both 12VDC and 24VDC applications
Operating temperature range: -40°C to +125°C
Strong shock resistance (50G) and vibration resistance
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12
3. Contact Form: One set of normally open
4. Number of Contacts: Single contact
5. Lead Form: Bolt-type
6. Mounting Type: With mounting plate
7. Package Type: Plastic-encapsulated
8. Lead Structure: Bolt-locked
9. Coil Power: Standard
10. Coil Characteristic: Monostable
11. Contact Material: AgSnO₂
12. Coil Parallel Component: Resistor
13. Packaging: Blister pack
14. Load Voltage: 12V
15. Rated Coil Power: 3.5W
16. Dielectric Withstand Voltage: 1000VAC, 1min
17. Operating Time: ≤35ms
18. Release Time: ≤20ms
19. Insulation resistance: 100MΩ
20. Maximum rated switching current (DC): 300
21. Maximum switching voltage (DC): 14
22. Temperature range: -40°C to 125°C
23. Mechanical endurance: 10,000,000 cycles
24. Electrical endurance: 30,000 cycles
25. Application Areas: Engine start preheating systems, power management systems, glow plugs, windshield heating, start/stop control
26. Weight: 220g
27. Volume: 281556mm³
12VDC Automotive Engine Start Preheat Relay HFV20-150/12-HAST-D1
US$ 7.57 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This 12VDC HFV20-150/12-HAST-D1 preheat relay is engineered to fit most 12V diesel and gasoline light trucks, passenger cars, and off-highway automotive equipment for seamless integration with existing engine preheating systems.
- Constructed with high-temperature resistant copper core contacts and a flame-retardant ABS housing, this preheat relay delivers 150A steady load capacity and exceptional resistance to vibration, corrosion, and harsh under-hood operating conditions.
- This is a brand new, OEM-equivalent engine start preheat relay that undergoes strict load testing and quality inspection before leaving the factory to match or exceed original part performance specifications.
- Designed to regulate power flow to your engine’s glow plug system in cold weather, this preheat relay cuts down crank time, reduces starter wear, and ensures smooth, consistent engine starts even in temperatures as low as -40°F.
- Each HFV20-150/12-HAST-D1 preheat relay ships in static-resistant, shock-absorbent packaging to prevent damage during transit, so you receive a fully functional, ready-to-install part straight out of the box.
