1 years
China
Compatible with Suzuki Models:
SV650 2003-2008/2017/2019/2022-2023
SV650S 2003-2008
Product Type Starter Solenoid Relay OEM Reference Part Number 31800-41G10, 31800-41F10, 31800-26G00 Rated Operating Voltage 12V DC Rated Continuous Current 30A Peak Withstand Current 80A Terminal Configuration 4-Pin, 2 x M6 Power Terminals + 2 x 6.3mm Spade Control Terminals Housing Material High Heat-Resistant Reinforced ABS Plastic Internal Contact Material Silver Alloy Operating Temperature Range -40°C to 125°C Waterproof & Dustproof Rating IP65 Mounting Hole Diameter 6mm / 0.24 Inch Fit Type Direct Plug-and-Play, No Drilling or Modification Required Package Inclusions 1 x Starter Relay, 2 x Matching Mounting Nuts Service Life ≥ 100,000 Operation Cycles
