Compatible with Suzuki Models:
VL1500 2013-2019
Part Type Starter Relay Solenoid OEM Cross Reference Part Numbers 31800-10G00, 31800-10G01, 31800-41F00, 240-54027 Rated Voltage 12V DC Terminal Configuration 4-terminal (2 x 6mm power terminals, 2 x 3mm signal terminals) Mounting Hole Diameter 6.5mm (0.26 inch) Housing Material High-temperature reinforced ABS plastic with zinc alloy mounting base Contact Material Silver-plated pure copper Operating Temperature Range -40°C to 125°C (-40°F to 257°F) Waterproof Protection Rating IP65 Minimum Service Life 100,000+ operation cycles Corrosion Resistance Grade Passed 48-hour neutral salt spray test Coil Resistance 12Ω ± 10%
