This planetary shaft is specially engineered for the Valeo D6G vehicle starter motor. It has a total length of 90 mm with a 10‑tooth left‑hand spline and a 30.9 mm main‑shaft diameter. Made of quenched‑tempered alloy steel, it resists frictional wear and torsional stress while cranking engines. It can replace damaged original shafts to maintain steady working performance of the Valeo D6G starter planetary‑gear assembly.
Specifications: Length 90mm, Teeth 10, Rotation LEFT, Central Axis φ30.9, Pin 5×13, Copper set φ6, Bearing file φ17, Outer plate φ43
Compatibility: Valeo D6G
Planetary Shaft for Valeo D6G 90mm 10 Teeth LEFT φ30.9
US$ 9.00 / 1 Piece
1Piece Minimum order
Brand:
xiaoxibian
oem:
XH-9-127
Material:
Quenched‑tempered alloy‑steel with strong torsion‑resistance and wear‑resistant performance
Key Specification:
Overall length 90 mm, 10‑tooth left‑hand spline, main‑shaft diameter φ30.9 mm for Valeo D6G starter
About this item
- This 10‑tooth left‑hand planetary shaft is an aftermarket replacement part for Valeo D6G automotive starter motor. Fitment: For Valeo D6G models with 90mm, 10 teeth, LEFT rotation, φ30.9 axis.
- Heat‑treated alloy‑steel endures continuous high‑speed rotation under heavy engine‑cranking loads. Specifications: Length 90mm, Teeth 10, Rotation LEFT, Central Axis φ30.9, Pin 5×13, etc.
- The 90‑mm‑long shaft with φ30.9 mm main‑axis meshes precisely with original planetary gear sets. Function: Critical for Valeo D6G planetary system.
- Reinforced shaft‑body structure prevents bending and twisting through repeated engine‑starting cycles. Durability: Built to Valeo D6G standards.
- OEM‑matched dimensions enable direct‑swap installation without modifying the starter housing. Replacement: Direct fit for Valeo D6G.
