Wire gauge: 16AWG, 18AWG
Wire length: 14.5mm
Voltage: 12V 24V
Relay Contact Form SPDT (Single Pole Double Throw) Contact Material Silver-nickel alloy Rated Switching Current 30A (Normally Open), 20A (Normally Closed) Insulation Resistance ≥100MΩ at 500V DC Dielectric Strength 1500V AC for 1 minute, no arcing or breakdown Operating Temperature Range -40℃ to +125℃ Mechanical Lifespan ≥10 million operation cycles Electrical Lifespan ≥100,000 operation cycles at full rated load Pin Function Arrangement Pin 85: Coil Ground, Pin 86: Coil Positive, Pin 30: Common Input, Pin 87: NO Output, Pin 87a: NC Output Wire Insulation Material Flame-retardant XLPE, UL94 V-0 flame rating Protection Grade IP67 for relay body, IP65 for wiring harness junction Coil Power Consumption 1.8W (12V version), 3.6W (24V version)
