Wide breadth but thin belt, excellent elastic and flexural property
.High transmission efficeincy under the operating environment of high-speed rotation, reverse flexure, small band pulley, etc.
.Core rubber with high tension and low elongation, while the consistent tension is maintained during the process of operation
.Excellent heat-resistance, oil-proof, and wearing resistance
.Less slip while large transmission effect during the process of operation
.Less noise during the process of operation
Size of Section
Type
Ribsection(mm)
Angle of rib(o)
Belt Thickness(mm)
Rib Numbers
Length range
PH
1.6
40
3
3-54
540-1270
PJ
2.34
40
4
3-36
540-18880
PK
3.56
40
4-6
3-23
600-2400
PL
4.7
40
10
3-16
900-3000
PM
9.4
40
17
3-8
1500-3000
