Characters
1. Small size dc brushless motor with low speed and big torque.
2. Suitable to small diameter, low noise and big torque application.
3. Can equip with Planetar Gear Reducer Compact size, Low noise Diameters as small as 12 mm Rated speed as low as 4rpm Torque up to 6000 mNm High torque, low Speed Ability to withstand harsh environments Long service life.
4. Reduction Ratio: 6、10、30、44、57、90、169、270、506、810.
Application
Robot,lock,Auto shutter, USB fan,Slot machine,Money detector
Coin refund devices,Currency count machine,Towel dispensers
Automatic doors,Peritoneal machine,Automatic TV rack,
Office equipment ,Household appliances,etc.
Parameters
1. Extended life: Brushless motors employ an electronic commutator rather than a mechanical commutator. There is no contact between the brush and the commutator. The life is several times longer than that of a brush motor.
2. Low interference: The brushless motor eliminates the brush and does not use an electric spark, reducing interference to other electronic devices.
3. Minimal noise: Due of the DC brushless motor's basic structure, spare and accessory parts may be accurately mounted. The running is relatively smooth, with a running sound of less than 50 decibels.
For the first time, there will be one. The rotation can be increased.
