Low-Profile ISO Micro Automotive Relay
Max Continuous Current: 20A (85°C)
Max Make Current: 100A
High Shock and Vibration Resistance
Dust Cover Type and Plastic-Sealed Type Available
1. Coil Voltage Type: DC
2. Coil Operating Voltage: 12V
3. Contact Form: One Set Normally Open
4. Number of Contacts: 1
5. Terminal Type: Quick Connect
6. Mounting Type: QC Terminals, Without Mounting Bracket/Panel
7. Package Type: Plastic Encapsulated
8. Terminal Structure: Standard Pin Length, Standard Pin Width, With Holes
9. Coil Power Rating: Standard
10. Coil Characteristic: Monostable
11. Contact Material: AgSnO₂
12. Coil Parallel Component: Diode
13. Packaging Type: Blister Pack
14. Load Voltage: 12V
15. Rated Coil Power: 0.9W
16. Dielectric Withstand Voltage: 500V
17. Actuation Time: 10ms
18. Release Time: 10ms
19. Insulation Resistance: 10MΩ
20. Maximum Rated Switching Current (DC): 20A
21. Maximum Switching Voltage (DC): 20.2V
22. Temperature Range: -40°C to 125°C
23. Mechanical Endurance: 10,000,000 cycles
24. Electrical endurance: 100,000 cycles (Refer to the catalog for more details)
25. Application fields: Window defogging, headlight control, seat heating control, horn control, fuel pump control, motor control, etc.
26. Weight: Approx. 11g
27. Dimensions: 22.5 × 15 × 15.7mm³
20A Seat Heater Control Automotive Relay HFV26/12-H1ST-D
US$ 8.57 / 1 Piece
1Piece Minimum order
Type:
Relay
Category:
Automotive
Brand:
Xiaoxibian
About this item
- This HFV26/12-H1ST-D 20A seat heater control relay is a direct plug-and-play fit for most 12V passenger vehicles and light trucks with factory or aftermarket heated seat systems, requiring no custom wiring to install.
- Built with heavy-duty corrosion-resistant copper terminals and a flame-retardant hard plastic housing, this relay maintains consistent 20A power delivery and resists wear from regular seat heater temperature cycling.
- This is a brand new, factory-calibrated OEM-equivalent seat heater relay, rigorously tested for proper function before shipping to eliminate defects or performance inconsistencies.
- Engineered to regulate power supply to automotive seat heating elements, this relay prevents overheating risks and ensures steady, even warmth across your vehicle’s heated seats for maximum passenger comfort.
- Each unit comes individually packed in an anti-static sealed bag to protect sensitive internal components from transit damage, so it arrives fully functional and ready for immediate installation.
